System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards System BIOS events
Revision 1.0 Intel order number G74211-001 71
11.2 System Firmware Progress (Formerly Post Error)
The BIOS logs any POST errors to the SEL. The two byte POST code gets logged in the ED2 and ED3 bytes in the SEL entry. This event will
be logged every time a POST error is displayed. Even though this event indicates an error, it may not be a fatal error. If this is a serious error,
there will typically also be a corresponding SEL entry logged for whatever was the cause of the error
– this event may contain more information
about what happened than the POST error event.
Table 70: POST Error Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 0001h = BIOS POST
11 Sensor Type
0Fh = System Firmware Progress (formerly POST
Error)
12 Sensor Number 06h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset = 0
15 Event Data 2 Low Byte of POST Error Code
16 Event Data 3 High Byte of POST Error Code
11.2.1 System Firmware Progress (Formerly Post Error) – Next Steps
See the following table for POST error Codes:
