System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards Power Subsystems
Revision 1.0 Intel order number G74211-001 27
Sensor Specific Offset
Description Next Steps
Hex Description
02h Predictive Failure Typically means a fan inside the power supply is not cooling the
power supply. It may indicate the fan is failing. Replace power supply
03h A/C lost AC removed Informational Event.
06h Configuration error Power supply configuration is not supported Indicates that at least one of the supplies is not correct for your system
configuration.
1) Remove the power supply and verify compatibility.
2) If power supply is compatible it may be faulty. Replace it.
4.3.2 Power Supply AC Power Input Sensors
These sensors will log an event when a power supply in the system is exceeding its AC power in threshold.
Table 21: Power Supply AC Power Input Sensors Typical Characteristics
Byte Field Description
11 Sensor Type 0Bh = Other Units
12 Sensor Number
52h = Power Supply 1 AC Power Input
53h = Power Supply 2 AC Power Input
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 01h(Threshold)
14 Event Data 1
[7:6] – 01b = Trigger reading in Event Data 2
[5:4] – 01b = Trigger threshold in Event Data 3
[3:0] – Event Trigger Offset as described in Table 22
15 Event Data 2 Reading that triggered event
16 Event Data 3 Threshold value that triggered event
