Sensor Cross Reference List System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
10 Intel order number G74211-001 Revision 1.0
Sensor
Number
Sensor Name Details Section Next Steps
1Eh
BB +1.35V P2 LV DDR3
(BB +1.35v P2 MEM)
Voltage Sensors Table 14: Voltage Sensors – Next Steps
20h
Baseboard Temperature
(Baseboard Temp)
Regular Temperature sensors Table 35: Temperature Sensors – Next Steps
21h
Front Panel Temperature
(Front Panel Temp)
Regular Temperature sensors Table 35: Temperature Sensors – Next Steps
22h
IOH Thermal Margin
(IOH Therm Margin)
Thermal Margin Sensors Table 38: Thermal Margin Sensors – Next Steps
23h
Processor 1 Memory Thermal
Margin
(Mem P1 Thrm Mrgn)
Thermal Margin Sensors Table 38: Thermal Margin Sensors – Next Steps
24h
Processor 2 Memory Thermal
Margin
(Mem P2 Thrm Mrgn)
Thermal Margin Sensors Table 38: Thermal Margin Sensors – Next Steps
30h –39h
Fan Tachometer Sensors
(Chassis specific
sensor names) Fan Speed Sensors Table 28: Fan Speed Sensor – Event Trigger Offset – Next Steps
40h –45h
Fan Present Sensors
(Fan x Present)
Fan Presence and Redundancy
Sensors
Table 30: Fan Presence Sensors – Event Trigger Offset – Next Steps
46h
Fan Redundancy
(Fan Redundancy)
Fan Presence and Redundancy
Sensors
Table 32: Fan Redundancy Sensor – Event Trigger Offset – Next Steps
50h
Power Supply 1 Status
(PS1 Status)
Power Supply Status Sensors Table 16: Power Unit Status Sensor – Sensor Specific Offsets – Next Steps
51h
Power Supply 2 Status
(PS2 Status)
Power Supply Status Sensors Table 16: Power Unit Status Sensor – Sensor Specific Offsets – Next Steps
52h
Power Supply 1
AC Power Input
(PS1 Power In)
Power Supply AC Power Input
Sensors Table 22: Power Supply AC Power Input Sensor – Event Trigger Offset – Next
Steps
53h
Power Supply 2
AC Power Input
(PS2 Power In)
Power Supply AC Power Input
Sensors Table 22: Power Supply AC Power Input Sensor – Event Trigger Offset – Next
Steps
