Power Subsystems System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
30 Intel order number G74211-001 Revision 1.0
Byte Field Description
14 Event Data 1
[7:6] – 01b = Trigger reading in Event Data 2
[5:4] – 01b = Trigger threshold in Event Data 3
[3:0] – Event Trigger Offset as described in Table 26
15 Event Data 2 Reading that triggered event.
16 Event Data 3 Threshold value that triggered event.
The following table describes the severity of each of the event triggers for both assertion and for deassertion.
Table 26: Power Supply Temperature Sensor – Event Trigger Offset – Next Steps
Event Trigger Offset Assertion
Severity
Deassert
Severity
Description Next Steps
Hex Description
07h
Upper non
critical going
high
Degraded OK An upper non-critical
or critical temperature
threshold has been
crossed.
1. Check for clear and unobstructed airflow into and out of chassis.
2. Ensure SDR is programmed and correct chassis has been selected.
3. Ensure there are no fan failures.
4. Ensure the air used to cool the system is within the thermal specifications for the system
(typically below 35°C).
09h
Upper critical
going high
non-fatal Degraded
