Chassis subsystem System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
78 Intel order number G74211-001 Revision 1.0
12. Chassis subsystem
The BMC monitors several aspects of the chassis. Next to logging when the power and reset buttons get pressed, the BMC also monitors
chassis intrusion if a chassis intrusion switch is included in the chassis; as well as looking at the network connections, and logging an event
whenever the physical network link is lost.
12.1 Physical Security
Two sensors are included in the physical security subsystem: chassis intrusion and LAN leash lost.
12.1.1 Chassis Intrusion
Chassis Intrusion is monitored on supported chassis, and the BMC logs corresponding events when the chassis lid is opened and closed.
12.1.2 LAN Leash lost
The LAN Leash lost sensor monitors the physical connection on the onboard network ports. If a LAN Leash lost event is logged this means the
network port lost its physical connection.
Table 72: Physical Security Sensor Typical Characteristics
Byte Field Description
11 Sensor Type 05h = Physical Security
12 Sensor Number 04h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as described in Table 73
