Hot Swap Controller events System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
88 Intel order number G74211-001 Revision 1.0
Byte Field Description
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1 40h = Failed Drive
15 Event Data 2 Not used.
16 Event Data 3 Not used.
14.2.1 HSC Drive Slot Status Sensor – Next Steps
If during normal operation a drive gets reported as failed then ensure that the drive was seated properly and the drive carrier was properly
latched. If that does not work then replace the drive.
14.3 HSC Drive Presence Sensor
The HSC Drive Slot Presence sensor will provide the current presence state for drive in each of the slots. After an AC power cycle there will be
a SEL entry to report the presence of the drive in a slot and there will be another entry for any changes in the presence of drives after that.
Table 84: HSC Drive Presence Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID
00C0h = HSC Firmware – HSBP A
00C2h = HSC Firmware – HSBP B
11 Sensor Type 0Dh = Drive Slot (Bay)
12 Sensor Number 6 Slot HSBP 8 Slot HSBP
