Basic decoding of a SEL Record
System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
6
Intel order number G74211-001
Revision 1.0
Table 2: Event Request Message Event Data Field Contents
Sensor
Class
Event Data
Threshold
Event Data 1
[7:6] - 00b = unspecified Event Data 2
01b = trigger reading in Event Data 2
10b = OEM code in Event Data 2
11b = sensor-specific event extension code in Event Data 2
[5:4] - 00b = unspecified Event Data 3
01b = trigger threshold value in Event Data 3
10b = OEM code in Event Data 3
11b = sensor-specific event extension code in Event Data 3
[3:0] - Offset from Event/Reading Code for threshold event.
Event Data 2
– reading that triggered event, FFh or not present if unspecified.
Event Data 3
– threshold value that triggered event, FFh or not present if unspecified. If present,
Event Data 2 must be present.
discrete
Event Data 1
[7:6] - 00b = unspecified Event Data 2
01b = previous state and/or severity in Event Data 2
10b = OEM code in Event Data 2
11b = sensor-specific event extension code in Event Data 2
[5:4] - 00b = unspecified Event Data 3
01b = reserved
10b = OEM code in Event Data 3
11b = sensor-specific event extension code in Event Data 3
[3:0] - Offset from Event/Reading Code for discrete event state
Event Data 2
[7:4] -
Optional offset from ‘Severity’ Event/Reading Code. (0Fh if unspecified).
[3:0] - Optional offset from Event/Reading Type Code for previous discrete event state. (0Fh if
unspecified.)
Event Data 3
– Optional OEM code. FFh or not present if unspecified.
OEM
Event Data 1
[7:6] - 00b = unspecified in Event Data 2
01b = previous state and/or severity in Event Data 2
10b = OEM code in Event Data 2
11b = reserved
[5:4] - 00b = unspecified Event Data 3
01b = reserved
10b = OEM code in Event Data 3
11b = reserved
[3:0] - Offset from Event/Reading Type Code
Event Data 2
[7:4] -
Optional OEM code bits or offset from ‘Severity’ Event/Reading Type Code. (0Fh if
unspecified).
[3:0] - Optional OEM code or offset from Event/Reading Type Code for previous event state. (0Fh if
unspecified).
Event Data 3 - Optional OEM code. FFh or not present or unspecified
