Power Subsystems System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
28 Intel order number G74211-001 Revision 1.0
The following table describes the severity of each of the event triggers for both assertion and for deassertion.
Table 22: Power Supply AC Power Input Sensor – Event Trigger Offset – Next Steps
Event Trigger Offset
Assertion
Severity
Deassert
Severity
Description Next Steps
Hex Description
07h
Upper non
critical going high
Degraded OK
PMBus* feature to monitor power
supply power consumption.
If you see this event, the system is pulling too much power on the input for the
PSU rating.
1. Verify the power budget is within the specified range.
2. Check http://www.intel.com/p/en_US/support/ for the power budget tool
for your system.
09h
Upper critical
going high
non-fatal Degraded
4.3.3 Power Supply Current Output % Sensors
PMBus* compliant power supplies may monitor the current output of the main 12v voltage rail and report the current usage as a percentage of
the maximum power output for that rail.
Table 23: Power Supply Current Output % Sensors Typical Characteristics
Byte Field Description
11 Sensor Type 03h = Current
12 Sensor Number
54h = Power Supply 1 Current Output %
55h = Power Supply 2 Current Output %
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 01h (Threshold)
14 Event Data 1
[7:6] – 01b = Trigger reading in Event Data 2
[5:4] – 01b = Trigger threshold in Event Data 3
[3:0] – Event Trigger Offset as described in Table 24
15 Event Data 2 Reading that triggered event
