PCI Express and Legacy PCI subsystem System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
64 Intel order number G74211-001 Revision 1.0
Byte Field Description
14 Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset as described in Table 64
15 Event Data 2 PCI Bus number
16 Event Data 3
[7:3] – PCI Device number.
[2:0] – PCI Function number
Table 64: PCI Express Correctable Error Sensor Event Trigger Offset – Next Steps
Event Trigger Offset
Description Next Steps
Hex Description
00h Receiver error Correctable error occurred
Informational event only. Correctable errors are acceptable and normal at a low rate of
occurrence. If error continues:
1. Decode bus, device, and function to identify the card.
2. If this is an add/in card:
a. Verify card is inserted properly.
b. Install the card in another slot and check if the error follows the card or
stays with the slot.
c. Update all firmware and drivers, including non-Intel ® components
3. If this is an onboard device:
a. Update all bios, firmware and drivers.
b. Replace the board.
01h Bad DLLP error Correctable bad DLLP occurred
02h Bad TLLP error Correctable bad TLP occurred
03h
REPLAY_NUM
Rollover Error
Correctable Replay event occurred
04h
REPLAY Timer
Timeout Error
Correctable Replay timeout event occurred
05h
Advisory non-fatal
Error (received
ERR_COR message)
Correctable advisory event occurred, typically
provided as notice to software driver
06h
Link bandwidth
changed
Link bandwidth changed
