System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards Manageability Engine (ME) events
Revision 1.0 Intel order number G74211-001 95
15.4 Node Manger Alert Threshold Exceeded
Policy Correction Time Exceeded Event will be sent each time when maintained policy power limit is exceeded over Correction Time Limit.
Table 88: Node Manager Alert Threshold Exceeded Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 002Ch – ME Firmware
11 Sensor Type DCh = OEM
12 Sensor Number 1Bh
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 72h (OEM)
14 Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3] = Node Manager Policy event
0 –Threshold exceeded
1 – Policy Correction Time Exceeded – policy did not meet the contract for the defined policy. The policy will continue to limit the
power or shutdown the platform based on the defined policy action.
[2] – Reserved
[1:0] – Threshold Number. valid only if Byte 5 bit [3] is set to 0
0 to 2 – threshold index
15 Event Data 2
[7:4] – Reserved
[3:0] – Domain Id (Currently, supports only one domain, Domain 0)
16 Event Data 3 Policy ID
