System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards PCI Express and Legacy PCI subsystem
Revision 1.0 Intel order number G74211-001 65
10.1.2 PCI Express Fatal Errors
When a PCI Express fatal error is reported to the BIOS SMI handler it will record the error using the following format.
Table 65: PCI Express Fatal Error Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 0033h = BIOS SMI Handler
11 Sensor Type 13h = Critical Interrupt
12 Sensor Number 04h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 70h (OEM Specific)
14 Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset as described in Table 66
15 Event Data 2 PCI Bus number
16 Event Data 3
[7:3] – PCI Device number
[2:0] – PCI Function number
