Manageability Engine (ME) events System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
92 Intel order number G74211-001 Revision 1.0
Byte Field Description
15 Event Data 2
[7:4] – Error type
0-9 - Reserved
10 – Policy Misconfiguration
11 – Power Sensor Reading Failure
12 – Inlet Temperature Reading Failure
13 – Host Communication error
14 – Real-time clock synchronization failure
15 – Platform shutdown initiated by NM policy due to execution of action defined by Policy Exception Action.
[3:0] – Domain Id (Currently, supports only one domain, Domain 0)
16 Event Data 3
if Error type= 10 or 15
if Error type = 11
if Error type = 12
Otherwise set to 0.
15.2.1 Node Manager Health Event – Next Steps
Misconfigured policy can happen if the max/min power consumption of the platform exceeds the values in policy due to hardware
reconfiguration.
First occurrence of an unacknowledged event will be retransmitted no faster than every 300 milliseconds.
Real-time clock synchronization failure alert is sent when NM is enabled and capable of limiting power, but within 10 minutes the firmware
cannot obtain valid calendar time from the host side, so NM cannot handle suspend periods.
Next steps will depend on the policy that was set. See the Node Manager Specification for more details.
