System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards Power Subsystems
Revision 1.0 Intel order number G74211-001 25
Byte Field Description
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 0Bh (Generic Discrete)
14 Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as described in Table 18
15 Event Data 2 Not used
16 Event Data 3 Not used
Table 18: Power Unit Redundancy Sensor – Event Trigger Offset – Next Steps
Event Trigger Offset
Description Next Steps
Hex Description
00h fully redundant System is fully operational Informational Event
01h redundancy lost
System is not running in redundant
power supply mode This event should be accompanied by specific power supply errors (AC
lost, PSU failure, and so on). Troubleshoot these events accordingly
02h redundancy degraded
03h non-redundant, sufficient from redundant
04h non-redundant, sufficient from insufficient
05h non-redundant, insufficient
06h non-redundant, degraded from fully redundant
07h redundant, degraded from non-redundant
4.3 Power Supply
The BMC monitors the power supply subsystem.
