83

Match Measurement

Distance to Fault (DTF) Measurement

Frequency Range

SA-3600XT
SA-6000XT

25 – 3600 MHz
25 – 6000 MHz

Frequency Resolution

25 – 800 MHz
800 – 3600 MHz
3600 – 6000 MHz

25 kHz
50 kHz
150 kHz

Frequency Accuracy

*

*. Accuracy only guaranteed when using the Bird Calibration Combo

listed in this manual (see Appendix Head, page 91).

± 100 kHz (25 MHz to 1 GHz)
± 50 ppm (1 GHz to 6 GHz)

Number of Data Points

238 (default), 475, 949

Measurement Range and

Resolution

Range

Return Loss

VSWR

Resolution

Return Loss

VSWR

0.0 to –60.0 dB

1.00 to 99.99

0.1 dB

0.01

Measurement Uncertainty

(after 1 display refresh)

*

Return Loss

VSWR

Determined graphically from composite of source

VSWR, instrumentation error, and directivity.

See Figure 75 on page 86.

Calculated from Return Loss

Mode

Internal

Resolution [R]

X-Axis

Y-Axis



Note: Where R = Resolution (meters)

Vp = Velocity of Propagation

Δ

F = Frequency Span (MHz)

0.1 dB, 0.01 VSWR

Range

X-Axis

Y-Axis

number of data points (238, 475, or 949) x R

0 to –60 dB

Accuracy

X-Axis

Y-Axis

± 2% of full-scale range with V

p

= 1

Same as for Return Loss Measurements

V

p

Range

0.20 to 1.00, or 1 to 99%

Max Distance

1000 meters

R

150

V

p

F

--------

=
