Specifications

Antenna Testing

Measurement Accuracy (after 1 display refresh)

Frequency Range

SA-3600XT
SA-6000XT

25 - 3600 MHz
25 - 6000 MHz

Frequency Resolution

25 – 800 MHz
800 – 3600 MHz
3600 – 6000 MHz

25 kHz
50 kHz
150 kHz

Number of Data Points

238 (default), 475, 949

Measurement Range and
Resolution

Return Loss
VSWR

Range

Resolution

0.0 to -60.0 dB

0.1 dB

1.00 to 99.99

0.01

Sweep Speed

238 data points
475 data points
949 data points

2.1 seconds / sweep
3.6 seconds / sweep
6.8 seconds / sweep

Measurement Uncertainty

*

(after 1 display refresh, 95% c.l.)

Return Loss

VSWR

*. When using Bird-specified calibration kit.

Determined graphically from composite of source
VSWR, instrumentation error, & directivity.
Calculated from Return Loss.

Test Port

Connectors
Impedance
VSWR, Max

<300 MHz
300 - 6000 MHz

Female N normally supplied
50 Ohms

2.10:1
1.35:1

Maximum Input Signal
(Damage Level)

+22 dBm

Output Power

0 dBm, nominal

Immunity to Interfering
Signals

 13 dB interferer at desired measurement
frequency

Return Loss

Determined Graphically from composite of:

Connector

Frequency

Directivity Phase Instrumentation Open/Short

N

25-3600 MHz

-42 dB

3 deg

-35 dB

≤ 0.09 dB

N

3600 -6000 MHz -38 dB

3 deg

7/16 DIN

25-3600 MHz

-40 dB

3 deg

7/16 DIN

3600 -6000 MHz -35 dB

3 deg
