Page 45

29
Setting the Maximum Distance
Note: Changing the frequency span or the max distance will auto-
matically turn calibration off. Always set the
frequency span or max distance before calibrating the unit.
1.
Enable the Fault Location Mode. See “Selecting Fault Location Mode” on
page 26.
2.
Press Enter, at the warning message, to accept the entry or Esc to cancel
the entry.
Note: When pressing Enter, the Site Analyzer will display the Cali-
bration screen so the calibration process can begin.
3.
Press the Config key.
4.
Press the Distance softkey.
5.
Press the right or left arrow keys to scroll to Max.
6.
Enter a maximum distance value.
7.
Press the Enter key after entering a value.
8.
Press the Esc key to exit the configuration screen.
Figure 21 Setting the Maximum Distance
Figure 22 Changed Max Distance Warning Message
