89
5015 Frequency Range 40 MHz - 4.0 GHz
Power Range -20.000 to +10.000 dBm
(10.0010 μW to 10.000 mW)
Measurements performed: True average power.
Accuracy ± 5% of Reading. When operating below 100 MHz and above
40 °C, add 1%.
5015-EF Frequency Range 40 MHz - 12 GHz
Power Range -20.000 to +10.000 dBm (10.0010 μW to 10.000 mW)
Measurements performed: True average power.
Accuracy ± 5% of Reading. When operating below 100 MHz and above
40 °C, add 1%
5016B Frequency Range 350 MHz - 4.0 GHz
Power Range 25 mW - 25 Watts Avg. 60 Watts Peak
Measurements performed: Peak power, true average power and
Duty Cycle.
Calculations Performed: VSWR, Return Loss, Reflection
Coefficient, Crest Factor, Average Burst Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.008 Watts Burst
Average Power = ±6% of reading, +0.008/D Watts Peak Envelope
Power = ±7% of reading, +0.05 Watts CCDF = ±0.2% typical
5017B Frequency Range 25 MHz - 1.0 GHz
Power Range 500 mW - 500 Watts Avg. 1300 Watts Peak
Measurements performed: Peak power, true
average power and Duty Cycle.
Calculations Performed: VSWR, Return Loss, Reflection
Coefficient, Crest Factor, Average Burst Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.17 Watts Burst
Average Power = ±6% of reading, +0.17/D Watts Peak Envelope
Power = ±7% of reading, +0.70 Watts CCDF = ±0.2% typical
5018B Frequency Range 150 MHz - 4.0 GHz
Power Range 100 mW - 25 Watts Avg. 60 Watts Peak
Measurements performed: Peak power, true average power and
Duty Cycle.
Calculations Performed: VSWR, Return Loss, Reflection
Coefficient, Crest Factor, Average Burst Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.008 Watts Burst
Average Power = ±6% of reading, +0.008/D Watts Peak Envelope
Power = ±7% of reading, +0.05 Watts CCDF = ±0.2% typical
5019B Frequency Range 25 MHz -1.0 GHz
Power Range 100 mW - 100 Watts Avg. 260 Watts Peak
Measurements performed: Peak power, true average power and
Duty Cycle.
Calculations Performed: VSWR, Return Loss, Reflection
Coefficient, Crest Factor, Average Burst Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.04 Watts Burst
Average Power = ±6% of reading, +0.04/D Watts Peak Envelope
Power = ±7% of reading, +0.13 Watts CCDF = ±0.2% typical
