B-4 AutoMax Network Communication Option Board
OCL TYPE 3 POSN REG EN
(P.814)
3 53 2
OIM COMM TIMEOUT (F00011) 1 10 13
OPEN ARMATURE (F00007) 1 10 7
OPEN SCR SENSITIVITY (P.600) 4 30
4 43
OPEN SCR TRIP THRESH (P.601) 4 31
4 44
Outer control loop enable 1 32 7
OVERSPEED (F00003) 1 10 9
Parameter processing error(s) 1 0 10
PLL MAXIMUM ERROR (P.308) 4 25
4 40
POS CURRENT LIM SEL (P.223) 2 57
POSITIVE CURRENT LIM (P.005) 1 44
2 5
PULSE TACH FEEDBACK (P.292) 3 1
PULSE TACH PPR (P.207) 3 22
3 62
PULSE TACH QUADRATURE
(P.208)
3 23
3 63
Ramp stop 1 26 4
RAMP STOP DECEL TIME (P.018) 2 33
REGULATOR SW VERSION (P.794) 1 31
REVERSE DISABLE (P.015) 2 17
2 62
Run 1 32 0
S - CURVE ROUNDING (P.014) 1 46
2 16
SCR # or MULTIPLE SCRS NOT
OPERATING (F00030–F00042)
1 10 10
SELF TUNE FAULT (F00060 to
F00099 )
1 10 3
Sequencing control word 1 32
SPD LEADLAG LOW FREQ
(P.214)
3 26
3 45
SPD LEADLAG RATIO (P.213) 3 25
3 44
SPD LEADLAG SELECT (P.216) 3 28
3 47
SPD LOOP ERROR (P.297) 3 2
SPD LOOP FEEDBACK (P.296) 1 3
Table B.1 – Cross Reference of Parameter Name to Drop and
Register (FlexPak 3000 Alternate Map) (Continued)
Parameter Name (No.) Drop Register Bit
SPD LOOP LAG BYPASS (P.217) 3 29
3 48
SPD LOOP LAG FREQ (P.215) 3 27
3 46
SPD LOOP OUTPUT (P.299) 1 4
SPD LOOP PI INIT SEL 2 32
SPD LOOP PI INIT VAL 1 39
SPD LOOP PI LEAD FREQ (P.212) 1 49
2 9
SPD LOOP PI PROP GAIN (P.211) 1 48
2 8
SPD LOOP PI RESET 1 32 6
SPD LOOP REFERENCE (P.295) 1 2
SPD SOURCE SEL OUT (P.193) 2 0
SPEED FEEDBACK GAIN 1 38
Stop 1 32 1
Stop asserted/Run de-asserted 1 26 0
Stop cause word 1 26
STOP DECEL SELECT (P.122) 3 53 3
STOP MODE SELECT (P.114) 2 53
STOP SPEED THRESHOLD
(P.113)
2 29
2 50
SUSTAINED OVERLOAD (F00005) 1 10 2
TACH LOSS SCR ANGLE (P.608) 2 43
TACHOMETER LOSS (F00002) 1 10 12
Terminal strip auto/manual 1 1 13
Terminal strip fault reset 1 1 7
Terminal strip forward/reverse 1 1 3
Terminal strip jog 1 1 4
Terminal strip run 1 1 2
Terminal strip stop 1 1 5
TOP SPEED (P.011) 2 13
2 61
TRIM MODE SELECT (P.110) 2 26
2 47
TRIM OUTPUT (P.197) 2 31
TRIM RANGE (P.109) 1 47
2 7
TRIM REF REGISTER (P.107) 2 24
TRIM REFERENCE SELECT
(P.108)
2 25
2 46
Table B.1 – Cross Reference of Parameter Name to Drop and
Register (FlexPak 3000 Alternate Map) (Continued)
Parameter Name (No.) Drop Register Bit
