Table 7.10 – WebPak 3000 Register Map, Drop_2: Master Write Registers, FULL Connection. Tunable Data (Drive Input Data)
Register Bit Parameter Name (Number) Description Settings
32 AutoMax Indirect Parameter 1 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 32 in Drop 3
33 AutoMax Indirect Parameter 2 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 33 in Drop 3
34 AutoMax Indirect Parameter 3 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 34 in Drop 3
35 AutoMax Indirect Parameter 4 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 35 in Drop 3
36 AutoMax Indirect Parameter 5 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 36 in Drop 3
37 AutoMax Indirect Parameter 6 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 37 in Drop 3
38 AutoMax Indirect Parameter 7 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 38 in Drop 3
39 AutoMax Indirect Parameter 8 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 39 in Drop 3
40 AutoMax Indirect Parameter 9 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 40 in Drop 3
41 AutoMax Indirect Parameter 10 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 41 in Drop 3
42 AutoMax Indirect Parameter 11 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 42 in Drop 3
43 AutoMax Indirect Parameter 12 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 43 in Drop 3
44 AutoMax Indirect Parameter 13 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 44 in Drop 3
45 AutoMax Indirect Parameter 14 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 45 in Drop 3
46 AutoMax Indirect Parameter 15 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 46 in Drop 3
47 AutoMax Indirect Parameter 16 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 47 in Drop 3
Tunable data are updated by the regulator approximately every 600 msec when Tune/Config Input Enable bit = 1.
