7-
18
Aut
o
Max
Net
w
or
k Comm
unicat
ion
O
p
tion
B
oard
51 AutoMax Indirect Register 20 Value to be written to the parameter selected in the
corresponding Drop 2 register
52 AutoMax Indirect Register 21 Value to be written to the parameter selected in the
corresponding Drop 2 register
53 AutoMax Indirect Register 22 Value to be written to the parameter selected in the
corresponding Drop 2 register
54 AutoMax Indirect Register 23 Value to be written to the parameter selected in the
corresponding Drop 2 register
55 AutoMax Indirect Register 24 Value to be written to the parameter selected in the
corresponding Drop 2 register
56 AutoMax Indirect Register 26 Value to be written to the parameter selected in the
corresponding Drop 2 register
57 AutoMax Indirect Register 27 Value to be written to the parameter selected in the
corresponding Drop 2 register
58 AutoMax Indirect Register 28 Value to be written to the parameter selected in the
corresponding Drop 2 register
59 AutoMax Indirect Register 29 Value to be written to the parameter selected in the
corresponding Drop 2 register
60 AutoMax Indirect Register 30 Value to be written to the parameter selected in the
corresponding Drop 2 register
61 AutoMax Indirect Register 31 Value to be written to the parameter selected in the
corresponding Drop 2 register
62 AutoMax Indirect Register 21 Value to be written to the parameter selected in the
corresponding Drop 2 register
Table 7.12 – WebPak 3000 Register Map, Drop_3: Master Write Registers, FULL Connection. Tunable/Configurable Data (Drive Input Data) (Continued)
Register Bit Parameter Name (Number) Description Settings
Configurable data are read by the regulator approximately every 600 msec when Tune/Config Input Enable bit=1 and the drive is not running or jogging.
