6-
12
Aut
o
Max
Net
w
or
k Comm
unicat
ion
O
p
tion
B
oard
23 ANLG MAN REF ZERO ADJ (P.105) Offset removed from the analog manual reference signal
24 TRIM REF REGISTER (P.107) Trim reference value % TOP SPEED (P.011) * 10
25 TRIM REFERENCE SELECT (P.108) Trim reference selection 0= REGISTER ; 1= ANALOG MANUAL ;
2= ANALOG IN 1; 3= NETW IN REG 1;
4= NETW IN REG 2; 5= NETW IN REG 3;
6= ANALOG IN 2
26 TRIM MODE SELECT (P.110) Type of trim mode selected 0= NO TRIM ; 1= INCREMENTAL ; 2= PROPORTIONAL
27 AUTO MODE MIN BYPASS (P.111) Disables minimum speed limit while in auto mode 0= OFF ; 1= ON (min speed bypassed)
28 AUTO MODE RAMP BYPASS (P.112) Bypasses speed loop S-curve block when drive in auto 0= OFF ; 1= ON (rate limit bypassed)
29 STOP SPEED THRESHOLD (P.113) Where the main contactor opens during a controlled stop RPM
30 Reserved
31 TRIM OUTPUT (P.197) Signal that trims selected speed/voltage loop reference 4095 at TOP SPEED (P.011)
Table 6.10 – FlexPak 3000 Alternate Register Map, Drop_2: Master Write Registers, FULL Connection. Tunable Data (Drive Input Data)
Register Bit Parameter Name (Number) Description Settings
33 RAMP STOP DECEL TIME (P.018) Ramp stop deceleration time when STOP DECEL SELECT
set to r AMP STOP DECEL TIME
seconds * 10
34 OCL REF REGISTER (P.801) Outer control loop reference 4095
35 OCL REF RAMP TIME (P.802) Ramp time for OCL reference seconds * 10
36 OCL REF ROUNDING (P.803) Amount of smoothing of the outer control loop reference %
37 OCL LEADLAG SELECT (P.805) Outer control loop lead/lag block select 0= LEAD / LAG ; 1= BYPASS ; 2= LAG / LEAD
38 OCL LEADLAG LOW FREQ (P.806) OCL lead/lag block low break frequency radians/second * 100
39 OCL LEADLAG RATIO (P.807) Ratio between low and high frequencies of OCL
40 JOG ACCEL / DECEL TIME (P.013) Minimum time in which the jog ref. can change from zero
to
TOP SPEED (P.011) and from TOP SPEED to zero
seconds * 10
41 ANLG AUTO GAIN ADJ (P.101) Scales analog auto reference signal gain * 1000
42 ANLG AUTO ZERO ADJ (P.102) Ooffset removed from analog auto reference zero
43 INV FAULT AVOID SEL (P.312) Inverting fault avoidance select 0= DISABLED ; 1= FAULT IMMEDIATELY ; 2= DELAY BEFORE FAULT
44 ANLG MAN REF GAIN ADJ (P.104) Scales the analog manual reference gain gain * 1000
Tunable data are read by the regulator approximately every 600 msec when Tune/Config Input Enable bit = 1.
Table 6.9 – FlexPak 3000 Alternate Register Map, Drop_2: Master Read Registers, FULL Connection. Tunable, Configurable, and Status Data (Drive Output Data) (Continued)
Register Bit Parameter Name (Number) Description Settings
Tunable, configurable, and status data are updated by the regulator approximately every 600 msec.
