F
lex
Pak
3000 Drives
: O
rig
inal Regist
er
M
a
p
5-
15
22
Stop cause word
Bit-packed word indicating why the drive stopped
0
Stop asserted or Run de-asserted (negated)
1
Jog de-asserted for less than 1 second
2
Internal stop request
3
Current limit stop
4
Ramp stop
5
Coast/DB stop
6
Fault stop or self-tuning complete
7
Customer interlock opened
8
Coast/DB interlock opened
9
Main contactor opened
10 – 15
Reserved
23
NOMINAL
AC
LINE
FREQ
(P.306)
Nominal AC line frequency
Hz
24
NOMINAL
AC
LINE
VOLTS
(P.307)
Nominal AC line
RMS
voltage
volts
RMS
25
PLL
MAXIMUM
ERROR
(P.308)
Max. allowed change in line period per AC line cycle
µsec
26
AC
LINE
VOLTAGE
(P.392)
Measured AC line
RMS
voltage
volts
RMS
27
ENHANCED
FLD
VOLT
ADJ
(P.500)
Adjusts the field output voltage
28
FIELD
ECONOMY
DELAY
(P.501)
Time between stopping and entering field economy
minutes
29
FIELD
ECONOMY
ACTIVE
(P.599)
Indicates the present state of field economy
0=
OFF
; 1=
ON
(field economy active)
30
OPEN
SCR
SENSITIVITY
(P.600)
Open
SCR
detection sensitivity adjustment
31
OPEN
SCR
TRIP
THRESH
(P.601)
Open
SCR
detection trip threshold
Table 5.16 – FlexPak 3000 Original Register Map, Drop_4: Master Read Registers, FULL Connection. Tunable, Configurable, and Status Data (Drive Output Data) (Continued)
Register
Bit
Parameter Name (Number)
Description
Settings
Tunable, configurable and status data are updated by the regulator approximately every 600 msec.
