Table 7.3 – WebPak 3000 Register Map, Drop_1: Master Read Registers, BASIC and FULL Connections. Runtime Signal Data (Drive Output Data)
Register Bit Parameter Name (Number) Description Settings
0 Drive status word 1 Bit-packed word containing information on the present status of the drive
0 Drive ready
1 Drive running
2 Fault active
3 Jogging forward
4 Jogging reverse
5 Underwind active
6 Stopping
7 Tension On active
8 Stall tension active
9 Current mem active
10 Current limit
11 Alarm active
12 Current/speed active
13 Processing error
14 Tune/cnfg enable
15 Network sync
1 Drive status word 2 Bit-packed word containing information on the present status of the drive
0 FN/DB status
1 Customer interlock
2 TB Section Run
3 TB Jog Reverse
4 TB Jog Forward
5 TB Section Off
6 Coast/DB interlock
7 TB Fault reset
8 TB Diameter Sel A
9 TB Diameter Sel B
10 TB Diameter Reset
Runtime signal data are updated by the regulator every 10 msec.
