7-
14
Aut
o
Max
Net
w
or
k Comm
unicat
ion
O
p
tion
B
oard
48 AutoMax Indirect Parameter 17 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 48 in Drop 3
49 AutoMax Indirect Parameter 18 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 49 in Drop 3
50 AutoMax Indirect Parameter 19 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 50 in Drop 3
51 AutoMax Indirect Parameter 20 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 51 in Drop 3
52 AutoMax Indirect Parameter 21 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 52 in Drop 3
53 AutoMax Indirect Parameter 22 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 53 in Drop 3
54 AutoMax Indirect Parameter 23 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 54 in Drop 3
55 AutoMax Indirect Parameter 24 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 55 in Drop 3
56 AutoMax Indirect Parameter 25 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 56 in Drop 3
57 AutoMax Indirect Parameter 26 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 57 in Drop 3
58 AutoMax Indirect Parameter 27 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 58 in Drop 3
59 AutoMax Indirect Parameter 28 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 59 in Drop 3
60 AutoMax Indirect Parameter 29 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 60 in Drop 3
61 AutoMax Indirect Parameter 30 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 61 in Drop 3
62 AutoMax Indirect Parameter 31 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 62 in Drop 3
63 AutoMax Indirect Parameter 32 Selects parameter to which the value in the
corresponding Drop 3 register is written Value of 0 disables register 63 in Drop 3
Table 7.10 – WebPak 3000 Register Map, Drop_2: Master Write Registers, FULL Connection. Tunable Data (Drive Input Data) (Continued)
Register Bit Parameter Name (Number) Description Settings
Tunable data are updated by the regulator approximately every 600 msec when Tune/Config Input Enable bit = 1.
