FlexPak 3000 Drives: Original Register Map 5-1
C
HAPTER
5
FlexPak 3000 Drives:
Original Register Map
This section lists the original register map, which allows you to use programs
developed for versions earlier than 4.0 of the FlexPak 3000 drive. It also offers a
different set of options in Drop_1 than the alternate register map.
Brief descriptions of parameters are in the register map tables. For detailed parameter
descriptions, refer to the
FlexPak 3000 DC Drive Software Reference Manual .
5.1 Accessing the Original Register Map
To access the original register map, set NETW REGISTER MAP SEL (P.914) to ORIGINAL .
Some parameters are not available and others are mapped differently when NETW
REGISTER MAP SEL (P.914) is set to ALTERNATE . Make sure your application uses the
correct mappings if you switch from the alternate register map to the original register map.
5.2 Finding Data in the Original Register Map Tables
The original register map shown in tables 5.2 through 5.18 describes the registers and
bits used by the FlexPak 3000 drive on the AutoMax network when
NETW REGISTER
MAP SEL (P.914) is set to ORIGINAL .
There are no write registers for control/reference data for Drop_2, Drop_3, and Drop_4.
Table 5.1 – Location of Information in the Original Register Map Tables
Drop_# Master… Data Type Table Page
1 Read Runtime Signal 5.2 5-2
Tunable, Configurable, and Status 5.3 5-4
Write Control/Reference 5.4 5-6
Tunable 5.5 5-7
Configurable 5.6 5-8
2 Read Runtime Signal 5.7 5-8
Tunable, Configurable, and Status 5.8 5-8
Write Tunable 5.9 5-9
Configurable 5.10 5-10
3 Read Runtime Signal 5.11 5-11
Tunable, Configurable, and Status 5.12 5-12
Write Tunable 5.13 5-12
Configurable 5.14 5-13
4 Read Runtime Signal 5.15 5-14
Tunable, Configurable, and Status 5.16 5-15
Write Tunable 5.17 5-16
Configurable 5.18 5-17
