Cross Reference of Parameter Name to Drop and Register (FlexPak 3000 Original Map) A-3
IET ( OVERCURRENT ) (F00001) 1 10 8
In current limit 1 0 9
INERTIA COMP SELECT (P.221) 2 56
Internal stop request 4 22 2
IR COMPENSATION (P.206) 1 55
3 21
Jog 1 32 3
JOG ACCEL / DECEL TIME (P.013) 2 15
2 40
Jog de-asserted < 1 second 4 22 1
JOG SPEED 1 (P.012) 1 53
2 14
Last alarm 1 14
Level Dectector Outputs 4 21 0& 1
LEVEL DETECT 1 DELAY (P.604) 4 37
LEVEL DETECT 1 SELECT (P.602) 4 60
LEVEL DETECT 1 THRESH (P.603) 4 36
LEVEL DETECT 2 DELAY (P.607) 4 39
LEVEL DETECT 2 SELECT (P.605) 4 61
LEVEL DETECT 2 THRESH (P.606) 4 38
Main contactor opened 4 22 9
MAXIMUM CURRENT (P.007) 3 12
3 58
MAXIMUM SPEED (P.004) 1 19
1 43
Memory save 1 32 11
MINIMUM SPEED (P.003) 1 18
1 42
MOTOR BRUSH WEAR LOW
(A00001)
1 13 0
MOTOR HOT FLD AMPS (P.510) 3 55
MOTOR RATED ARM AMPS
(P.008)
3 13
3 59
MOTOR RATED ARM VOLTS
(P.009)
3 14
3 60
MOTOR THERMOSTAT TRIP
(F00008)
1 10 4
NEG CURRENT LIM SEL (P.224) 2 58
NEGATIVE CURRENT LIM (P.006) 1 21
1 45
Table A.1 – Cross Reference of Parameter Name to Drop and
Register (FlexPak 3000 Original Map) (Continued)
Parameter Name (No.) Drop Register Bit
NETW COMM LOSS SELECT
(P.901)
1 29
1 57
NETW CONNECT TYPE (P.910) 1 28
1 62
NETW IN REG 1 (P.905) 1 34
NETW IN REG 2 (P.906) 1 35
NETW IN REG 3 (P.907) 1 36
NETW OUT REG 1 SELECT
(P.902)
1 58
NETW OUT REG 2 SELECT
(P.903)
1 59
NETW OUT REG 3 SELECT
(P.904)
1 60
NETWORK COMMUNICATION
TIMEOUT (F00013)
1 10 14
Network Output Register 1 1 7
Network Output Register 2 1 8
Network Output Register 3 1 9
Network Reference 1 33
NOMINAL AC LINE FREQ (P.306) 4 23
4 62
NOMINAL AC LINE VOLTS (P.307) 4 24
4 63
NORMALIZED INERTIA (P.222) 2 33
OCL FEEDBACK SELECT (P.804) 2 60
OCL LEADLAG LOW FREQ (P.806) 2 38
OCL LEADLAG RATIO (P.807) 2 39
OCL LEADLAG SELECT (P.805) 2 37
OCL OUTPUT (P.848) 1 21
2 12
OCL PI LEAD FREQ (P.809) 2 52
OCL PI NEGATIVE LIMIT (P.811) 2 54
OCL PI POSITIVE LIMIT (P.810) 2 53
OCL PI PROP GAIN (P.808) 2 51
OCL RAMP OUTPUT (P.846) 2 11
OCL REF RAMP TIME (P.802) 2 35
OCL REF REGISTER (P.801) 2 34
OCL REF ROUNDING (P.803) 2 36
OCL REFERENCE SELECT
(P.800)
2 59
OCL TRIM RANGE (P.812) 2 55
Table A.1 – Cross Reference of Parameter Name to Drop and
Register (FlexPak 3000 Original Map) (Continued)
Parameter Name (No.) Drop Register Bit
