Table 7.9 – WebPak 3000 Register Map, Drop_2: Master Read Registers, FULL Connection. Tunable, Configurable, and Status Data (Drive Output Data)
Register
Bit
Parameter Name (Number)
Description
Settings
15
AC
LINE
PERIOD
(P.393)
AC line period as measured by the drive in
microseconds
16
ARMATURE
BRIDGE
POL
(P.394)
Indicates which bridge is currently active.
OFF
(forward bridge active;
ON
(reverse
bridge active)
17
ARMATURE
DELTA
(P.399)
Armature firing angle in microseconds
18
CML
FEEDBACK
(P.397)
CML
feedback signal after scaling
19
CML
RAMP
INPUT
TP
(P.390)
Current reference value to the
CML
ramp block
20
CML
SPEED
REFERENCE
(P.391)
Speed reference value to the current minor loop
21
CURRENT
COMPOUND
TP
(P.293)
Trim value that is subracted from the speed reference
based on motor load
22
DIAMETER
ANALOG
(P.821)
Output of the diameter calculator scaled from zero at
empty core to 4095 at full roll diameter
23
DIAMETER
RESET
TP
(P.829)
State of the diameter reset signal
24
DRAW
PERCENTAGE
OUT
(P.196)
Product of the selectrd trim reference value and trim
range value
25
ENCODER
KIT
(P.798)
Indicates if Pulse Encoder kit is installed and passed
diagnostics
INSTALLED
;
NOT
INSTALLED
;
FAILED
DIAGS
26
FIELD
DELTA
(P.588)
Field firing angle indegrees
0 to 180 degree
27
FIELD
ECONOMY
ACTIVE
(P.599)
State of the field economy function
ON
;
OFF
28
FLD
CURRENT
REGULATOR
(P.586)
Indicates if the Field Current Regulator kit is installed
and its rating
NOT
INSTALLED
; 4
AMP
, 10
AMP
, 20
AMP
29
INERTIA
COMPENSATION
(P.244)
Output of the inertia compensation calculator
30
IR
COMPENSATION
TP
(P.290)
Level of
IR
compensation being subtracted from the
measured armature voltage
31
DIAMETER
CALC
OUTPUT
(P.132)
Value of the calculated roll diameter normalized at
1.000 at
EMPTY
CORE
DIAMETER
(P.830)
Tunable, configurable, and status data are updated by the regulator approximately every 600 msec.
