Chapter 5 Create an RSLogix 5000 Software Project
Electronic Keying
The electronic keying feature automatically compares the expected module, as
shown in the RSLogix 5000 I/O Configuration tree, to the physical module
before I/O communication begins. You can use electronic keying to help prevent
communication to a module that does not match the type and revision expected.
For each module in the I/O Configuration tree, the user-selected keying option
determines if, and how, an electronic keying check is performed. Typically, three
keying options are available:
•
Exact Match
•
Compatible Keying
•
Disable Keying
You must carefully consider the benefits and implications of each keying option
when selecting between them. For some specific module types, fewer options are
available.
Electronic keying is based on a set of attributes unique to each product revision.
When a Logix5000 controller begins communicating with a module, this set of
keying attributes is considered.
You can find revision information on the General tab of a module’s Properties
dialog box.
Table 4 - Keying Attributes
Attribute
Description
Vendor
The manufacturer of the module, for example, Rockwell Automation/Allen-Bradley.
Product Type
The general type of the module, for example, communication adapter, AC drive, or digital I/O.
Product Code
The specific type of module, generally represented by its catalog number, for example, 1756-IB16I.
Major Revision
A number that represents the functional capabilities and data exchange formats of the module. Typically, although not always, a later,
that is higher, Major Revision supports at least all of the data formats supported by an earlier, that is lower, Major Revision of the same
catalog number and, possibly, additional ones.
Minor Revision
A number that indicates the module’s specific firmware revision. Minor Revisions typically do not impact data compatibility but may
indicate performance or behavior improvement.
