Rockwell Automation Publication 1757-UM012A-EN-P - July 2011
159
Appendix
C
Fieldbus Status Codes
for RSLogix 5000 Projects
Introduction
The status codes in this appendix are in the controller tags of projects created in
the RSLogix 5000 programming software.
Input Parameters
Topic
Page
Table 24 - FFLD1:0:I.In[0].xxxxxx
Fieldbus Status
Logix Status - FFLD1:0:I.In[0].xxxxxx
Quality
Sub-status
Limits
Quality
Substatus
WindupL
WindupH
Init
Primary
Initializing
Initiate
Fault State
Bad
Non-Specific
Not Limited
0
0
0
0
0
0
0
Low Limited
0
0
1
0
0
0
0
High Limited
0
0
0
1
0
0
0
Constant
0
0
1
1
0
0
0
Configuration Error
Not Limited
0
1
0
0
0
0
0
Low Limited
0
1
1
0
0
0
0
High Limited
0
1
0
1
0
0
0
Constant
0
1
1
1
0
0
0
Not Connected
Not Limited
0
2
0
0
0
0
0
Low Limited
0
2
1
0
0
0
0
High Limited
0
2
0
1
0
0
0
Constant
0
2
1
1
0
0
0
Device Failure
Not Limited
0
3
0
0
0
0
0
Low Limited
0
3
1
0
0
0
0
High Limited
0
3
0
1
0
0
0
Constant
0
3
1
1
0
0
0
