Rockwell Automation Publication 1757-UM012A-EN-P - July 2011
57
Create an RSFieldbus Software Project Chapter 3
5.
Repeat
and
for all desired parameters.
6.
Click Close.
The edited parameters are added to the block.
Online Characterization
Once your project is online, you can edit the device parameters. Changes are
saved to the device, but you must save the project upon closing for the
configuration file to contain the same modifications.
1.
In the Fieldbus (H1) window, right-click the desired block and choose
On Line Characterization.
The On Line Characterization dialog box appears.
2.
Click
to view all parameters.
3.
Select a desired parameter and click Edit at the bottom of the dialog box.
4.
Enter a value and click End Edit.
5.
Repeat
for all desired parameters.
6.
Click Close.
The edited parameters are added to the block.
Delete a Parameter
To delete a parameter once it has been configured in the Characterization dialog
box, right-click the corresponding icon in the Fieldbus (H1) or Process Cell
window and choose Delete Parameter.
Customize Characterization Parameters
This option lets you customize specific function blocks with parameters listed in
the Characterization dialog box. Do these steps.
1.
In the Fieldbus (H1) pr Process Cell window, right-click the desired block
and choose Customize Characterization.
