Rockwell Automation Publication 1757-UM012A-EN-P - July 2011 67
Chapter
4
RSFieldbus Communication
Introduction This section describes how to set up an RSFieldbus project to communicate with
field devices. A project must be created and a bridge module (linking device)
must
be in the configuration.
The linking device, such as the 1757-FFLD shown in Figure 6, provides
connectivity for fieldbus devices to Logix controllers via H1 networks.
Figure 6 - Linking Device Connectivity Example
The table lists the main topics described in this section.
STATUS
WD0G BATT NS MODE
H1-1
H1-2
H1-3
H1-4
FOUNDATION Fieldbus
FOUNDATION Fieldbus Linking Device
A B
H-1
Ethernet network to
Logix controller and
RSFieldbus workstation.
1757-FFLD
Power Supply
Power Conditioner
Field Devices
45584
H-1
Topic Page
Initialize Communication 68
Assign Tags 71
Download the Configuration 74
