Overview of Remaining
Configuration Procedures
Chapter 4
4-5
Table 4.A
Information Required to Download a Block
Block to
Download:
ProĆSet 600
Block ID.:
ProĆSet 600
Download Bit B21/
Companion
Block:
JGC 02 1
FCC 03 2 CPC
SCC 04 3 CPC
TCC 05 4 CPC
LPC 06 5 CPC
CPC 07 6
INC 08 7 IPC
IPC 09 8
PKC 10 9 HPC
HDC 11 10 HPC
HPC 12 11
PRC 13 12
PLC 14 13 PPC
PPC 15 14
PSC 16 15
FOC 17 16 OPC
SOC 18 17 OPC
TOC 19 18 OPC
OSC 20 19 OPC
OPC 21 20
EAC 22 21 EPC
ERC 23 22 EPC
EPC 24 23
2. Confirm that the QDC module returns the ID in SYS61.
Important: If the value returned in SYS61 is NOT the ID number
you entered, you have an error in the MCC or DYC block:
If SYS61 has
this value:
This block
has errors:
Fix them as follows:
1 MCC Refer to chapter 3 Correct Programming Errors in MCC"
25 DYC Go to steps 8 and 9 of this procedure.
Fix MCC and DYC errors before starting the download procedure
MCC and DYC errors are corrected when SYS61
≠
1 or 25, but
when SYS61=DYC61=ID number of the subject block
When you have done all three: Then:
1. Corrected all errors in MCC and DYC blocks
2. Entered the ID of the subject block in DYC61
3. Downloaded the subject block
The QDC module immediately
reports any programming errors it
detected in the subject block
