Chapter 3 Wire Your Controller
1762-IF2OF2 Output Type Selection
The output type selection, current or voltage, is made by wiring to the
appropriate terminals, Iout or Vout,
and by the type/range selection bits in the
Configuration Data File. Refer to MicroLogix 1400
Programmable Controllers
Instruction Set Reference Manual, publication
.
1762-IF2OF2 Wiring
The following illustration shows the 1762-IF2OF2 analog expansion I/O
terminal block.
ATTENTION: Analog outputs may fluctuate for less than a second
when power is applied or removed. This characteristic is common
to most analog outputs. While the majority of loads will not
recognize this short signal, it is recommended that preventive
measures be taken to ensure that connected equipment is not
affected.
