Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)
Prototypes Files" to 9, N Data files 50 to 58 are reserved to store the structure of
the Data Set Prototypes configuration.
As an example, with Data Set Descriptors files, if you configure "Data Set
Descriptors Object File Number" to 60 and "Maximum Number of Data Set
Descriptors File" to 9, N Data files 60 to 68 are reserved to store the structure of
the Data Set Descriptors configuration.
Once the Data Set Prototypes and Descriptors are configured in the DNP3 Slave
Application Layer Configuration of RSLogix500/RSLogix Micro software, you
can see the DNP3 DS Prototype X and DNP3 DS Descriptor X trees under the
Data Set Prototypes file N50
Data Set Prototypes
Element Array
(N data file)
Data Set Prototypes file N51
Data Set Prototypes file N52
Data Set Prototypes file N53
Data Set Prototypes file N54
Data Set Prototypes file N58
...
Data Set Descriptors file N60
Data Set Descriptors
Element Array
(N data file)
Data Set Descriptors file N61
Data Set Descriptors file N62
Data Set Descriptors file N63
Data Set Descriptors file N64
Data Set Descriptors file N68
...
