Rockwell Automation Publication 1766-UM001H-EN-P - May 2014
165
Troubleshooting Your System Appendix C
Calling Rockwell
Automation for Assistance
If you need to contact Rockwell Automation or local distributor for assistance, it
is helpful to obtain the following (prior to calling):
• controller type, series letter, revision letter, and firmware (FRN) number of
the controller
• controller indicator status
Hardware-Specific
Error
X210
001
0 0001 0000
Reserved
Configuration Error
X400
010
0 0000 0000
General configuration error; no additional information
X401
010
0 0000 0001
Invalid input data format selected (channel 0)
X402
010
0 0000 0010
Invalid input data format selected (channel 1)
X403
010
0 0000 0011
Invalid output data format selected (channel 0)
X404
010
0 0000 0100
Invalid output data format selected (channel 1)
(1)
X represents “Don’t Care”.
Extended Error Codes for 1762-IF2OF2
Error Type
Hex Equivalent
(1)
Module Error
Code
Extended Error
Information Code
Error Description
Binary
Binary
Extended Error Codes for 1762-IF4 and 1762-OF4
Error Type
Hex Equivalent
(1)
Module
Error Code
Extended Error
Information Code
Error Description
Binary
Binary
No Error
X000
000
0 0000 0000
No error
General Common
Hardware Error
X200
001
0 0000 0000
General hardware error; no additional information
X201
001
0 0000 0001
Power-up reset state
Hardware-
Specific Error
X300
001
1 0000 0000
Reserved
Configuration Error
X400
010
0 0000 0000
General configuration error; no additional information
X401
010
0 0000 0001
Invalid range select (Channel 0)
X402
010
0 0000 0010
Invalid range select (Channel 1)
X403
010
0 0000 0011
Invalid range select (Channel 2)
X404
010
0 0000 0100
Invalid range select (Channel 3)
X405
010
0 0000 0101
Invalid filter select (Channel 0) – 1762-IF4 only
X406
010
0 0000 0110
Invalid filter select (Channel 1) – 1762-IF4 only
X407
010
0 0000 0111
Invalid filter select (Channel 2) – 1762-IF4 only
X408
010
0 0000 1000
Invalid filter select (Channel 3) – 1762-IF4 only
X409
010
0 0000 1001
Invalid format select (Channel 0)
X40A
010
0 0000 1010
Invalid format select (Channel 1)
X40B
010
0 0000 1011
Invalid format select (Channel 2)
X40C
010
0 0000 1400
Invalid format select (Channel 3)
(1)
X represents “Don’t Care”.
