Specifications Appendix A
Specifications for Outputs in Hazardous Locations
(Class 1, Division 2, Groups A, B, C, D)
Relay Outputs
Description
1766-L32AWA/A,
1766-L32BWA/A
1766-L32BXB/A
Maximum controlled load
1440 VA
1080 VA
Maximum Continuous Current:
Current per channel and group
common
2.5 A per channel
8A max channel 8...11
common
2.5 A per channel
Current per
controller
at 150V max
28 A or total of per-point
loads, whichever is less
at 240V max
20 A or total of per-point
loads, whichever is less
Relay Outputs
Description
1766-L32AWA/A, 1766-L32BWA/A, 1766-L32BXB/A
Turn On Time/Turn Off Time
10 msec (maximum)
(1)
(1)
Scan time dependent
Load current
10 mA (minimum)
Maximum Volts
Amperes
Amperes
Continuous
Volt-Amperes
Make
Break
Make
Break
240V AC
7.5 A
0.75 A
2.5 A
1800 VA
180 VA
120V AC
15.0 A
1.5 A
2.5 A
1800 VA
180 VA
250V DC
0.11 A
1.0 A
28 VA
125V DC
0.22 A
1.0 A
28 VA
