MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
Diagnostic File Number in Secure Authentication
This parameter is supported only in MicroLogix 1400 Series B controllers.
The diagnostic file number is used to store the diagnostics for the
troubleshooting of DNP3 Secure Authentication subsystem.
The value of this parameter is N file only. Valid range is 0, 7, 9 to 255. Default
value is 0.
See the table for the contents of the data file in the section Diagnostics.
Default Variation Config File Number
This parameter is supported only in MicroLogix 1400 Series B controllers.
8
Update Key (6)
0
0
0 to 65535
9
Update Key (7)
0
0
0 to 65535
10
User Number
0
0
0 to 65535
For User 2
11
Reserved
0
0
0
For User 1
12
Update Key (0)
0
0
0 to 65535
13
Update Key (1)
0
0
0 to 65535
14
Update Key (2)
0
0
0 to 65535
15
Update Key (3)
0
0
0 to 65535
16
Update Key (4)
0
0
0 to 65535
17
Update Key (5)
0
0
0 to 65535
18
Update Key (6)
0
0
0 to 65535
19
Update Key (7)
0
0
0 to 65535
…
90
User Number
0
0
0 to 65535
For User 10
91
Reserved
0
0
0
For User 10
92
Update Key (0)
0
0
0 to 65535
93
Update Key (1)
0
0
0 to 65535
94
Update Key (2)
0
0
0 to 65535
95
Update Key (3)
0
0
0 to 65535
96
Update Key (4)
0
0
0 to 65535
97
Update Key (5)
0
0
0 to 65535
98
Update Key (6)
0
0
0 to 65535
99
Update Key (7)
0
0
0 to 65535
DNP3 Secure Authentication User Info Configuration File Structure
Word Offset
Name
Default Value By
Controller (DEC)
Default Value By
RSLogix500 (DEC)
Valid Range (DEC)
Description
