System Loading and Heat Dissipation Appendix H
Calculating Heat
Dissipation
Use the following table when you need to determine the heat dissipation of your
system for installation in an enclosure. For System Loading, take the value from
the appropriate system loading worksheets on pages 345 or 347.
Validating Systems using 1766-L32AWA or 1766-L32BXB
Maximum Allowable Values
Calculated Values
Current:
Current (Subtotal from Table .):
1225 mA at 5V DC
1155 mA at 24V DC
mA @ 5V DC
mA @ 24V DC
System Loading:
System Loading:
33.845 W
= (________ mA x 5V) + (________ mA x 24V)
= __________ mW + __________ mW
= __________ mW
= __________ W
Validating Systems using 1766-L32BWA
Maximum Allowable Values
Calculated Values
Current for Devices Connected to the +24V DC Sensor
Supply:
Sum of all sensor currents
250 mA @ 24V DC
mA @ 24V DC
Current for MicroLogix Accessories and Expansion I/O:
Current (Subtotal from Table .)
1225 mA @ 5V DC
1155 mA @ 24V DC
mA @ 5 V DC
mA @ 24V DC
System Loading:
System Loading:
39.845 W
= (________ mA x 24V) + (________ mA x 5V) + (________ mA x 24V)
= __________ mW + __________ mW + __________ mW
= __________ mW
= __________ W
Heat Dissipation
Catalog Number
Heat Dissipation
Equation or Constant
Calculation
Sub-Total
1766-L32AWA
15.2 W + (0.4 x System Loading)
15.2 W + (0.4 x ______ W)
W
1766-L32BWA
15.7 W + (0.4 x System Loading)
15.7 W + (0.4 x ______ W)
W
1766-L32BXB
17.0 W + (0.3 x System Loading)
17.0 W + (0.3 x ______ W)
W
1762-IA8
2.0 W x number of modules
2.0 W x _________
W
1762-IF4
2.0 W x number of modules
2.0 W x _________
W
1762-IF2OF2
2.6 W x number of modules
2.6 W x _________
W
1762-IQ8
3.7 W x number of modules
3.7 W x _________
W
1762-IQ16
5.4 W
(1)
x number of modules
5.4 W
(1)
x _________
W
1762-IQ32T
6.8 W x number of modules (@ 30.0V DC)
5.4 W x number of modules (@ 26.4V DC)
6.8 W x _________ (@ 30.0V DC)
5.4 W x _________ (@ 26.4V DC)
W
W
1762-IR4
1.5 W x number of modules
1.5 W x _________
W
1762-IT4
1.5 W x number of modules
1.5 W x _________
W
1762-OA8
2.9 W x number of modules
2.9 W x _________
W
