Rockwell Automation Publication 1766-UM001H-EN-P - May 2014
307
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
60
Application Layer Error Codes:
0: NO_ERROR - No error found in the Application Layer.
1: FC_CANNOT_BROADCAST - Reserved
2: FC_NOT_SUPPORTED - The received packet has unsupported
Function Code.
3: OBJ_NOT_SUPPORTED - The received packet has unsupported
object(s).
4: BAD_REQUEST_LENGTH - Reserved
5: CONFIGURATION_ERROR - The error was caused by the invalid
configuration during packet generating. E.g. invalid Data Set
Configuration.
6: BAD_PARAMETER - The received packet has invalid parameters
except Function Code and Object Codes. E.g. invalid Qualifier codes.
7: BAD_FILE_TYPE - The error was caused by invalid configuration in
DNP3 Slave Application Layer. Invalid File Type specified.
8: BAD_FILE_NUMBER - The error was caused by invalid
configuration in DNP3 Slave Application Layer. Invalid File Number
specified.
9: BAD_DNP3_ADDRESS - The error was caused by invalid
configuration in DNP3 Slave Application Layer. Invalid File Number
specified.
10: TABLE_WRITE_PROTECTED - The specified DNP3 object data file
has been locked to be written.
11: TABLE_ACCESS_DENIED - The specified DNP3 object data file
has been locked to be read or written.
12: TABLE_OWNERSHIP_ERROR - The specified DNP3 object data
file has been locked to be read or written.
If an error code is within 6 to 12, related file number and element
number are shown in word 64 and 65.
DNP3 Slave - Application Layer Diagnostics for DNP3
Slave.
61
Application Layer Error Count
62
Function Code that caused the last error
63
Last Transmitted IIN in the response
64
Data file number of last error request
65
Data element number of last error request
66
Received Confirm Function Code Counter
67
Received Read Function Code Counter
68
Received Write Function Code Counter
69
Received Function Code Counter other than Confirm, Read and Write
Function Codes.
70
Transmitted Solicited Response Function Code Counter
71
Transmitted Unsolicited Response Function Code Counter
72
Number of events to be reported.
Data File for Troubleshooting
Word Offset
Description
Category
