Specifications Appendix A
Common mode rejection
(2)
> 55 dB at 50 and 60 Hz
> 55 dB at 50 and 60 Hz
>110 dB at 50 Hz (with 10 or
50 Hz filter)
>110 dB at 60 Hz (with 10 or
60 Hz filter)
>110 dB at 50 Hz (with 10 or
50 Hz filter)
>110 dB at 60 Hz (with 10 or
60 Hz filter)
Non-linearity (in percent full
scale)
±0.12%
(4)
±0.05% NA
Typical overall accuracy
(3)
±0.55% full scale at
-20…65 °C
±0.3% full scale at 25 °C
±0.32% full scale at
-20…65 °C
±0.24% full scale at 25 °C
±0.5 °C (F °) for Pt 385
NA
Input impedance
Voltage Terminal: 200 K
Ω
Current Terminal: 250
Ω
Voltage Terminal: 200 K
Ω
Current Terminal: 275
Ω
>10
ΜΩ
>10
ΜΩ
Current input protection
±32 mA
±32 mA
NA
NA
Voltage input protection
±30V
±30V
NA
NA
Channel diagnostics
Over or under range or open
circuit condition by bit
reporting for analog inputs.
Over or under range or open
circuit condition by bit
reporting for analog inputs.
Over or under range or open
circuit condition by bit
reporting for analog inputs.
Over or under range or open
circuit condition by bit
reporting for analog inputs.
(1) For proper operation, both the plus and minus input terminals must be within ±27V (±10V for 1762-IT4) of analog common.
(2) V
cm
= 1 V
pk-pk
AC
(3) V
cm
= 0 (includes offset, gain, non-linearity and repeatability error terms)
(4) Only applicable to Series B I/O modules.
Input Specifications
Specification
1762-IF2OF2
1762-IF4
1762-IR4
1762-IT4
