Programming 6–11
Setup
[Overload Amps]
This value should be set to the motor nameplate Full Load
Amps (FLA) for 1.15 SF motors. For 1.0 SF motors the
value should be set to 0.9 x nameplate FLA.
Parameter Number 38
Parameter Type Read and Write
Display Units / Drive Units 0.1 Amps / 4096 = Rated Amps
Factory Default 115% of Drive Rating
115.0% of Drive Rating Firmware 5.001 & later
Minimum Value 20% of Drive Rated Amps
0.0% of Drive Rated Amps Firmware 5.001 & later
Maximum Value 115% of Drive Rated Amps
115.0% of Drive Rated Amps Firmware 5.001 & later
[VT Scaling]
This parameter scales the drive for VT ampere ratings.
Important: This parameter must be set to “Disabled” when
drive is used in a fibers application.
This parameter cannot be changed while the drive is
running.
Parameter Number 203
Parameter Type Read and Write
Factory Default “Disabled”
Units Display Drive
“Disabled” 0 Disables Variable Torque Scaling
“Enabled” 1 Enables Variable Torque Scaling
[Motor NP RPM]
This value should be set to the motor nameplate rated
RPM.
This parameter cannot be changed while the drive is
running.
Parameter Number 177
Parameter Type Read and Write
Display Units / Drive Units 1 RPM / 1 RPM
Factory Default 1750 RPM
Minimum Value 60 RPM
Maximum Value 24000 RPM
[Motor NP Hertz]
This value should be set to the motor nameplate rated
frequency.
This parameter cannot be changed while the drive is
running.
Parameter Number 178
Parameter Type Read and Write
Display Units / Drive Units 1 Hertz / Hertz x 10
Factory Default 60 Hz
Minimum Value 1 Hz
Maximum Value 400 Hz
[Motor NP Volts]
This value should be set to the motor nameplate rated
volts.
This parameter cannot be changed while the drive is
running.
Parameter Number 190
Parameter Type Read and Write
Display Units / Drive Units 1 Volt / 4096 = Drive Rated Volts
Factory Default Drive Rated Volts
Minimum Value 0 Volts
Maximum Value 2 x Drive Rated Volts
[Motor NP Amps]
This value should be set to the motor nameplate rated
current.
This parameter cannot be changed while the drive is
running.
Parameter Number 191
Parameter Type Read and Write
Display Units / Drive Units 1 Amp / 4096 = Drive Rated Amps
Factory Default Drive Rated Amps
Minimum Value 0 Amps
Maximum Value 2 x Drive Rated Amps
