2–8 Installation/Wiring
Table 2.A (continued)
575 Volt Input Protection Devices
1 Minimum protection device size is the lowest rated device that supplies maximum protection without nuisance tripping.
2 Maximum protection device size is the highest rated device that supplies drive protection.
3 Circuit Breaker - inverse time breaker.
4 Motor Circuit Protector - instantaneous trip circuit breaker.
5 Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip.
6 Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 208 Wye or Delta, 240 Wye or Delta, 480Y/277 or 600Y/ 347. Not UL listed for use on 480V
or 600V Delta/Delta systems.
7 The AIC ratings of the Bulletin 140M Motor Protector may vary. See publication 140M-SG001B-EN-P.
8 Maximum rating allowed by US NEC. Exact size must be chosen for each installtion.
9 The Maximum Short Circuit Rating of a Cutler-Hammer Series HMCP is 100,000A at 240 volts, 65,000A at 480 volts and 25,000A at 575 volts.
Table 2.B
deleted
Fr
am
e
Drive
Catalog
Number
1336F-
CT Ratings
Dual Element
Time Delay Fuse Non-Time
Delay Fuse
Circuit
Breaker
3
Motor
Circuit
Protector
4,9 140M Motor Starter with Adjustable Current Range 5, 6
HP
Input Output
Amps Amps Min. 1 Max. 2 Min. 1 Max. 2 Max. 8 Max. 8 Available Catalog Numbers 7
A4 F10 1 2.4 2.0 3 3 3 6 15 3 140M-C2E-B25 – – –
F20 2 4.8 4.0 6 6 6 10 15 7 140M-C2E-C63 140M-D8E-C63 – –
F30 3 7.2 6.0 10 12 10 15 15 7 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 –
F50 5 9.6 8.0 15 20 15 20 20 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 –
F75 7.5 10.0 10.0 15 20 15 30 35 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 –
F100 10 12.0 12.0 20 25 20 40 40 15 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 –
F150 15 19.0 19.0 25 35 25 60 60 30 140M-C2E-C20 140M-D8E-C20 140M-F8E-C20 140-CMN-2500
F200 20 25.0 24.0 30 45 30 80 80 30 140M-C2E-C25 140M-D8E-C25 140M-F8E-C25 140-CMN-2500
C 025 25 31.0 30.0 40 60 40 100 100 50 – – 140M-F8E-C32 140-CMN-4000
030 30 36.0 35.0 50 70 50 125 125 50 – – 140M-F8E-C45 140-CMN-4000
040 40 44.0 45.0 60 90 60 150 150 70 – – 140M-F8E-C45 140-CMN-6300
050 50 55.0 57.0 80 110 80 200 200 70 – – – 140M-CMN-6300
060 60 60.0 62.0 90 125 90 225 225 100 – – – 140M-CMN-6300
D 075 75 84.0 85.0 110 150 110 300 300 100 – – – 140M-CMN-9000
100 100 108.0 109.0 150 200 150 350 350 150 – – – –
125 125 137.0 138.0 175 250 175 500 350 250 – – – –
E 150 150 167.0 168.0 225 300 225 500 400 250 – – – –
200 200 251.0 252.0 350 400 350 600 500 250 – – – –
250 250 282.0 284.0 400 500 400 700 700 400 – – – –
X300 300 295.0 298.0 400 600 400 800 800 400 – – – –
F P350 350 347.0 350.0 450 Semiconductor fuse supplied with drive.
Refer to the 1336 Spare Parts list (publication 1336-6.5) for replacement information. P400 400 397.0 400.0 500
G 300 300 297.0 300.0 400
Bussmann Type FWP, SPP, or 170M Series
Ferraz Shawmut Type A-70Q, A-70QS or A070URD Series
350 350 347.0 350.0 450
400 400 397.0 400.0 500
450 450 446.0 450.0 600/630
500 500 496.0 500.0 800
600 600 595.0 600.0 800
