Installation/Wiring 2–19
Table 2.F
Maximum Motor Cable Length Restrictions in meters (feet) - 380V-480V Drives
1
Type A Motor Characteristics: No phase paper or misplaced phase paper, lower quality insulation systems, corona inception voltages between 850 and 1000 volts.
Type B Motor Characteristics: Properly placed phase paper, medium quality insulation systems, corona inception voltages between 1000 and 1200 volts.
1329R/L Motors:
These AC variable speed motors are “Control-Matched” for use with Allen-Bradley Drives. Each motor is designed to meet or exceed
the requirements of the Federal Energy Act of 1992. All 1329R/L motors are optimized for variable speed operation and include premium
inverter grade insulation systems which meet or exceed NEMA MG1. Part 31.40.4.2.
Drive
Frame Drive kW
(HP) Motor kW
(HP)
No External Devices w/1204-TFB2 Term. w/1204-TFA1 Terminator Reactor at Drive 2
Motor Motor Motor Motor
A B 1329
1600V or
1329R/L (1850V)
A or B 1329 A B 1329 A B or 1329
Any
Cable Any
Cable Any
Cable Any
Cable
6
Cable Type
Any
Cable
Cable Type Cable Type
Any
Cable Any
Cable Any
Cable
Shld. 3 Unshld. Shld. 3 Unshld. Shld. 3 Unshld.
A1 0.37 (0.5) 0.37 (0.5) 12.2
(40)
33.5
(110) 91.4
(300) 91.4
(300) 30.5
(100) 61.0
(200) 30.5
(100) 61.0
(200) 91.4
(300) 22.9
(75) 182.9
(600)
0.75 (1) 0.75 (1) 12.2
(40) 33.5
(110) 91.4
(300) 91.4
(300) 30.5
(100) 30.5
(100) 30.5
(100) 30.5
(100) 91.4
(300) 22.9
(75) 182.9
(600)
0.37 (0.5) 12.2
(40)
33.5
(110) 91.4
(300) 91.4
(300) Use 1204-TFA1 30.5
(100) 61.0
(200) 30.5
(100) 61.0
(200) 91.4
(300) 22.9
(75) 182.9
(600)
1.2 (1.5) 1.2 (1.5) 12.2
(40) 33.5
(110) 91.4
(300) 91.4
(300) 30.5
(100) 30.5
(100) 61.0
(200) 61.0
(200) 91.4
(300) 22.9
(75) 182.9
(600)
0.75 (1) 12.2
(40) 33.5
(110) 91.4
(300) 91.4
(300) 30.5
(100) 30.5
(100) 61.0
(200) 61.0
(200) 91.4
(300) 22.9
(75) 182.9
(600)
0.37 (0.5) 12.2
(40)
33.5
(110) 114.3
(375) 121.9
(400) 30.5
(100) 30.5
(100) 61.0
(200) 61.0
(200) 121.9
(400) 22.9
(75) 182.9
(600)
A2 1.5 (2) 1.5 (2) 7.6
(25) 12.2
(40) 91.4
(300) 91.4
(300) 91.4
(300) 91.4
(300) 91.4
(300) 30.5
(100) 30.5
(100) 91.4
(300) 61.0
(200) 91.4
(300) 22.9
(75) 182.9
(600)
1.2 (1.5) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 91.4
(300) 182.9
(600) 182.9
(600) 30.5
(100) 30.5
(100) 91.4
(300) 61.0
(200) 182.9
(600) 22.9
(75) 182.9
(600)
0.75 (1) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 30.5
(100) 30.5
(100) 91.4
(300) 61.0
(200) 182.9
(600) 22.9
(75) 182.9
(600)
0.37 (0.5) 7.6
(25)
12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 30.5
(100) 30.5
(100) 91.4
(300) 61.0
(200) 182.9
(600) 22.9
(75) 182.9
(600)
2.2 (3)
2.2 (3) 7.6
(25) 12.2
(40) 91.4
(300) 91.4
(300) 182.9
(600) 182.9
(600) 182.9
(600)
Use 1204-TFB2
22.9
(75) 182.9
(600)
1.5 (2) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
0.75 (1) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
0.37 (0.5) 7.6
(25)
12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
A3 3.7 (5)
3.7 (5) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600)
Contact factory for
advice on cable
lengths over 182.9
(600).
182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
2.2 (3) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
1.5 (2) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
0.75 (1) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
0.37 (0.5) 7.6
(25)
12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 22.9
(75) 182.9
(600)
A4 5.5-15
(7.5-20) 5.5-15
(7.5-20) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 24.4
(80) 182.9
(600)
B 11-22
(15-30) 11-22
(15-30) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 24.4
(80) 182.9
(600)
C 30-45
(X40-X60) 30-45
(40-60) 7.6
(25) 12.2
(40) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 76.2
(250) 182.9
(600)
D 45-112
(60-X150) 45-112
(60-150) 12.2
(40) 30.5
(100) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 61.0
(200) 182.9
(600)
E 112-187
(150-250) 112-187
(150-250) 12.2
(40) 53.3
(175) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600)
F 187-336
(250-450) 187-336
(250-450) 18.3
(60) 53.3
(175) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600)
G 187-448
(X250-600) 187-448
(250-600) 18.3
(60) 53.3
(175) 114.3
(375) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600) 182.9
(600)
