Programming 6–7
Metering
[Torque Current]
This parameter displays the amount of current that is in
phase with the fundamental voltage component. It is the
current that is actually producing torque.
Parameter Number 162
Parameter Type Read Only
Display Units / Drive Units 0.1 Amp / 4096 = 100% Drive Rated Amps
Factory Default None
Minimum Value –200% Drive Rating
Maximum Value +200% Drive Rating
[Flux Current]
This parameter displays the amount of current that is out
of phase with the fundamental voltage component. It is the
current that is producing motor flux.
Parameter Number 163
Parameter Type Read Only
Display Units / Drive Units 0.1 Amp / 4096 = 100% Drive Rated Amps
Factory Default None
Minimum Value – 200% Drive Rating
Maximum Value +200% Drive Rating
[% Output Power]
This parameter displays the % of drive rated output power
(kw). Refer to the Ratings Group or drive data nameplate.
Parameter Number 3
Parameter Type Read Only
Display Units / Drive Units 1 % /
±4096 = ±100%
Factory Default None
Minimum Value 200% Drive Rated Output Power
Maximum Value +200% Drive Rated Output Power
[% Output Curr]
This parameter displays the % of drive rated output current.
Refer to the Ratings Group or drive data nameplate.
Parameter Number 2
Parameter Type Read Only
Display Units / Drive Units 1 % / 4096 = 100%
Factory Default None
Minimum Value 0%
Maximum Value 200% Rated Drive Output Current
[Elapsed Run Time]
This parameter displays the elapsed running time of the
drive. The meter is resettable to any value by
reprogramming.
Parameter Number 279
Parameter Type Read and Write
Display Units / Drive Units 0.1 Hr / Hours x 10
Factory Default 0
Minimum Value 0
Maximum Value 6553.5
