Human Interface Module
3–9
EEProm Mode (continued)
Press these keys . . .
while following these steps . . .
The HIM Display will show . . .
Drive -> HIM
2. To upload a parameter profile from the drive to the HIM, you must have
a compatible HIM (see
A. From the EEProm menu (see steps A-C above), press the Incre-
ment/Decrement keys until “Drive -> HIM” is displayed.
B. Press Enter. A profile name (up to 14 characters) will be displayed
on line 2 of the HIM. This name can be changed or a new name
entered. Use the SEL key to move the cursor left. The Increment/
Decrement keys will change the character.
C. Press Enter. An informational display will be shown, indicating the
drive type and firmware version.
D. Press Enter to start the upload. The parameter number currently
being uploaded will be displayed on line 1 of the HIM. Line 2 will
indicate total progress. Press ESC to stop the upload.
E. “COMPLETE” displayed on line 2 will indicate successful upload.
Press Enter. If “ERROR” is displayed, see Chapter 7.
EEProm
Drive -> HIM
Drive -> HIM
1 A
Master Type
Version 2.01
Drive -> HIM 60
|||||
Drive -> HIM 210
COMPLETE
HIM -> Drive
3. To download a parameter profile from the HIM to a drive, you must
have a compatible HIM (see
Important: The download function will only be available when there is
a valid profile stored in the HIM.
A. From the EEProm menu (see steps 1A-1C), press the Increment/
Decrement keys until “HIM -> Drive” is displayed.
B. Press the Enter key. A profile name will be displayed on line 2 of
the HIM. Pressing the Increment/Decrement keys will scroll the dis-
play to a second profile (if available).
C. Once the desired profile name is displayed, press the Enter key. An
informational display will be shown, indicating the version numbers
of the profile and drive.
D. Press Enter to start the download. The parameter number currently
being downloaded will be displayed on line 1 of the HIM. Line 2 will
indicate total progress. Press ESC to stop the download.
E. A successful download will be indicated by “COMPLETE” displayed
on line 2 of the HIM. Press Enter. If “ERROR” is displayed, see
Chapter 7.
EEprom
HIM -> Drive
HIM -> Drive
1 A
Master Type
2.01 -> 2.03
HIM -> Drive 60
|||||
Drive -> HIM 210
COMPLETE
or
or
&
or
or
&
