Specifications and Supplemental Information A–17
Read/Write Parameter Record When using a compatible HIM (see Table 3.A ), the parameters listed
can be uploaded to the HIM for downloading to other drives.
No. Name Setting No. Name Setting No. Name Setting No. Name Setting
5 Freq Select 1 ______
6 Freq Select 2 ______
7 Accel Time 1 ______
8 Decel Time 1 ______
9 Control Select ______
10 Stop Select 1 ______
11 Bus Limit En ______
12 DC Hold Time ______
13 DC Hold Level ______
14 Run On Power Up ______
15 Reset/Run Time ______
16 Minimum Freq ______
17 Base Frequency ______
18 Base Voltage ______
19 Maximum Freq ______
20 Maximum Voltage ______
22 MOP Increment ______
24 Jog Frequency ______
25 Anlg Out 0 Sel ______
27 Preset Freq 1 ______
28 Preset Freq 2 ______
29 Preset Freq 3 ______
30 Accel Time 2 ______
31 Decel Time 2 ______
32 Skip Freq 1 ______
33 Skip Freq 2 ______
34 Skip Freq 3 ______
35 Skip Freq Band ______
36 Current Limit ______
37 Overload Mode ______
38 Overload Amps ______
39 Flt Clear Mode ______
40 Line Loss Fault ______
41 Motor Type ______
42 Slip @ F.L.A. ______
43 Dwell Frequency ______
44 Dwell Time ______
45 PWM Frequency ______
46 Encoder PPR ______
47 Language ______
48 Start Boost ______
49 Break Frequency ______
50 Break Voltage ______
52 Stop Select 2 ______
56 S Curve Time ______
57 S Curve Enable ______
58 Common Bus ______
73 Preset Freq 4 ______
74 Preset Freq 5 ______
75 Preset Freq 6 ______
76 Preset Freq 7 ______
77 Speed Control ______
78 Traverse Inc ______
79 Max Traverse ______
80 P Jump ______
81 Blwn Fuse Flt _______
82 Cur Lim Trip En _______
83 Run Boost _______
85 Reset/Run Tries _______
90 Analog Trim En _______
91 Low Bus Fault _______
92 Logic Mask _______
93 Local Mask _______
94 Direction Mask _______
95 Start Mask _______
96 Jog Mask _______
97 Reference Mask _______
98 Accel Mask _______
99 Decel Mask _______
100 Fault Mask _______
101 MOP Mask _______
111 Data In A1 _______
112 Data In A2 _______
113 Data In B1 _______
114 Data In B2 _______
115 Data In C1 _______
116 Data In C2 _______
117 Data In D1 _______
118 Data In D2 _______
119 Data Out A1 _______
120 Data Out A2 _______
121 Data Out B1 _______
122 Data Out B2 _______
123 Data Out C1 _______
124 Data Out C2 _______
125 Data Out D1 _______
126 Data Out D2 _______
127 Process 1 Par _______
128 Process 1 Scale _______
129 Process 1 Txt 1 _______
130 Process 1 Txt 2 _______
131 Process 1 Txt 3 _______
132 Process 1 Txt 4 _______
133 Process 1 Txt 5 _______
134 Process 1 Txt 6 _______
135 Process 1 Txt 7 _______
136 Process 1 Txt 8 _______
150 4-20mA Loss Sel _______
151 Maximum Speed _______
152 Encoder Type _______
154 Anlg Out 0 Offst _______
155 Flying Start En _______
156 FStart Forward _______
157 FStart Reverse _______
158 CR1 Out Select _______
159 Dig Out Freq _______
160 Dig Out Current _______
161 Dig Out Torque _______
164 Speed KP _______
165 Speed KI _______
169 Boost Slope ______
170 Rated Amps ______
171 Rated kW ______
172 EEPROM Cksum ______
173 Fault Alarms 1 ______
174 CR2 Out Select ______
175 CR3 Out Select ______
176 CR4 Out Select ______
177 Motor NP RPM ______
178 Motor NP Hertz ______
180 Process 2 Par ______
181 Process 2 Scale ______
182 Process 2 Txt 1 ______
183 Process 2 Txt 2 ______
184 Process 2 Txt 3 ______
185 Process 2 Txt 4 ______
186 Process 2 Txt 5 ______
187 Process 2 Txt 6 ______
188 Process 2 Txt 7 ______
189 Process 2 Txt 8 ______
190 Motor NP Volts ______
191 Motor NP Amps ______
192 Flux Amps Ref ______
193 KP Amps ______
194 IR Drop Volts ______
195 Slip Comp Gain ______
200 Flux Up Time ______
201 Motor OL Fault ______
203 VT Scaling ______
204 Ground Warning ______
206 Alarm Mask 1 ______
213 PI Config ______
215 PI Ref Select ______
216 PI Fdbk Select ______
221 KI Process ______
222 KP Process ______
223 PI Neg Limit ______
224 PI Pos Limit ______
225 PI Preload ______
226 Shear Pin Fault ______
227 Adaptive I Lim ______
228 LLoss Restart ______
229 Freq Ref SqRoot ______
230 Save MOP Ref ______
231 Hold Level Sel ______
232 Current Lmt Sel ______
233 Anlg Out 0 Abs ______
234 Anlg Out 0 Lo ______
235 Anlg Out 0 Hi ______
237 Anlg In 0 Lo ______
238 Anlg In 0 Hi ______
239 Anlg In 1 Lo ______
240 Anlg In 1 Hi ______
241 Input Mode ______
242 TB3 Term 22 Sel ______
243 TB3 Term 23 Sel _____
244 TB3 Term 24 Sel _____
245 TB3 Term 26 Sel _____
246 TB3 Term 27 Sel _____
247 TB3 Term 28 Sel _____
248 Anlg In 2 Lo _____
249 Anlg In 2 Hi _____
250 Anlg Signal Loss _____
256 Line Loss Mode _____
264 Pulse In Scale _____
267 Dig At Temp _____
268 Motor Therm Flt _____
271 Alarm Mask 2 _____
274 Anlg Out 1 Sel _____
275 Anlg Out 1 Lo _____
276 Anlg Out 1 Hi _____
277 Anlg Out 1 Abs _____
278 Anlg Out 1 Offst _____
280 Pulse Out Select _____
281 Pulse Out Scale _____
282 Enc Count Scale _____
283 Encoder Counts _____
284 Encoder Loss Sel _____
288 Bus Regulation _____
289 Phase Loss Det _____
290 Load Loss Detect _____
291 Load Loss Level _____
292 Load Loss Time _____
303 Current Lmt En ______
304 Traverse Dec _____
305 Traverse Mask _____
307 Sync Time _____
308 Sync Mask _____
310 Sync Loss Sel _____
311 Sync Loss Gain _____
312 Sync Loss Time _____
313 Sync Loss Comp _____
315 Alt Type 2 Cmd _____
317 Run/Accel Volts _____
319 Speed Brake En ______
320 Line Loss Volts _____
321 Loss Recover _____
322 Ride Thru Volts _____
323 Min Bus Volts _____
324 Stability Gain ______
325 Bus Reg/Max Bus ______
326 Remote CR Output ______
327 At Time ______
328 Max Enc Counts ______
329 Bidir In Offset ______
330 Phase Loss Mode ______
331 Phase Loss Level ______
332 Precharge Fault ______
333 PWM Comp Time ______
334 Break Freq/PWM ______
