5–2 Start-Up
Initial Operation 1. Verify that AC line power at the disconnect device is within the
rated value of the drive. If a Control Interface option (L4, L5, L6,
L4E through L9E) is installed, verify that the control power to
this board matches the board rating.
2. Remove and lock-out all incoming power to the drive including
incoming AC power to terminals R, S and T (L1, L2 and L3) plus
any separate control power for remote interface devices.
3. If a Control Interface option is installed, verify that the Stop and
Enable interlock inputs are present.
Important: The Stop and Enable inputs must be present before the
drive will start.
If this option is not installed, verify that two jumpers are installed
at pins 3 & 4 and 17 & 18 of J2. In addition, the [Input Mode]
must be set to “Status.”
4. Confirm that all other optional inputs are connected to the correct
terminals and are secure.
5. The remainder of this procedure requires that a HIM be installed.
If the HIM has a Control Panel, use the local controls to complete
the start-up procedure. If a Control Panel is not present, remote
devices must be used to operate the drive.
6. Proceed to “Assisted Start-Up” . If a more detailed start-up is
required, go to “Advanced Start-Up” on page 5 .
Assisted Start-Up The following procedure provides a prompted start-up. Steps
are outlined below.
!
ATTENTION: To guard against possible machine damage
and/or personal injury caused by unintended motor rotation,
Do Not press the Start key (HIM) or issue a Start command
(TB3) during the Start-Up procedure until instructed to do
so. Pressing the Start key or issuing a Start command will
cause the drive to start.
Assisted Start-Up
Keys Description The HIM Display will show . . .
Disconnect Load from
Motor
1. For proper operation of the Autotune function, assure that the load is discon-
nected from the motor.
Apply Power 2. Apply AC power and control voltages to the drive. The LCD Display should
light and display a drive status of “Stopped” and an output frequency of “+0.00
Hz.”
If the drive detects a fault, a brief statement relating to the fault will be shown
on the display. Record this information, remove all power and correct the fault
source before proceeding. Refer to Chapter 7 for fault descriptions.
Stopped
+0.00 Hz
