Chapter 6
Installation
6-40
Node Adapter Board
The Node Adapter Board is connected to Microbus Port B and is not
preconfigured. Refer to the Node Adapter manual for configuration and
installation information.
Multi-Communication Adapter Board
The Multi-Communication Board is not preconfigured. Refer to the
Multi-Communication Adapter manual for configuration and installation
information.
Table 6.P
Terminal Torque Values
Terminals
L1 – L3
AC Input
Amps
Wire
Range
Torque
In. – Lbs.
L1 – L3 2.9 – 45.7 4 – 14 45
– 46.5 – 89.8 2 – 8 50
TB1 14 Max. 5
TB2 22 – 12 5
TB3 22 – 10 6.2
TB4 22 – 12 6.2
Table 6.Q
Terminal Torque Values
Armature
Amps
Wire Range
of Lug
Torque
In. - Lbs.
3.6 – 56 4 – 14 45
57 – 80 2 – 8 50
81 – 180 4/0 – 2 250
*141 – 345 250 MCM – 6 275
*2 wires per lug
Armature Current Ratings The following tables provide nameplate data information to help you size
wires during installation.
