Chapter 1
Introduction, Inspection & Storage, and
Publication References
1-5
Enable/Contingency
Coast Stop –
System Reset –
Motor Thermostat –
Communication Port – 24VDC/115VAC, hard–wired to DC
contactor
24VDC/115VAC, Isolated
24VDC/115VAC, Isolated
RS–422 for programming terminal
External Inputs:
Drive Ready/Faulted–
N.O. relay contact, open when drive faulted
or de–energized, closed when ready. Con-
tact rating – 1 ADC @ 24 VDC or 0.5A @
120VAC
External Outputs:
Ambient Operating
Temperature
Relative Humidity
Altitude
0
°
to 55
°
C (32
°
– 130
°
F)
5% to 95%, non–condensing
3,300 feet (1,000 meters)
Environmental
Accel/Decel
Preset Speeds
Jog Speeds
“S” Ramp
Motor Operated Pot
(MOP)
0.1 to 6554 seconds, independently
programmable.
5 adjustments, programmable
2 adjustments, programmable
Programmable
10 adjustments, programmable
Standard Features
Discrete Adapter
Board;
Digital Inputs (4) –
Digital Outputs (2) –
Analog Inputs (4) –
Analog Outputs (4) –
Power Supply (For
external use) –
24VDC or 120VAC, 10 mA. NOTE: A
separate board and part number is used for
each voltage rating.
Dry relay contacts rated at 0.6 amps at
125VAC or 2.0 amps at 30VDC.
0 to +/– 10 VDC, differential input imped-
ance – 20K ohms.
–10 to + 10VDC, 1mA minimum output
impedance – 200 ohms.
+10VDC, 4mA maximum, –10VDC,
4mA maximum.
Options
Incremental, dual channel; 12 volts,
500mA, isolated with differential transmit-
ter, 102.5 kHz max. Quadrature : 90
° ±
27
°
@ 25
°
C, Duty Cycle: 50%
±
10% Source/
Sink capable, A–B 845H or equal.
Feedback Devices:
Encoder –
DC Tachometer – 5 PY, BC42 or equal
