Chapter 6
Installation
6-19
Table 6.H
Field Current Jumper Setting
J1 Jumper
on Fdbk Bd
1
2
3
4
Field Current Range
1-30 HP, 240VDC
2-60 HP, 500VDC
4.5 to 10.6A DC
2.0 to 4.6A DC
0.5 to 2.1A DC
0.15 to 0.6A DC
Field Current Range
40-100 HP, 240VDC
75-200 HP, 500VDC
9.1 to 21.2A DC
4.1 to 9.2A DC
1.1 to 4.2A DC
0.4 to 1.2A DC
125-300 HP, 240VDC
250-600 HP, 500VDC
18.3 to 42.4A DC
8.6 to 18.4A DC
2.3 to 8.7A DC
1.0 to 2.4A DC
J1 Jumper
on PSI /Switcher
1
2
3
4
2. Verify that the voltage selection for the Reset and Motor Thermostat
inputs is correct. Jumpers J11 and J12 on the Power Stage Interface
Board determine whether the voltage used for the Reset and Motor
Thermostat inputs is 24VDC or 115VAC. Both switches should be in
the same position (See Table 6.I).
Table 6.I
Power Stage Interface Board Jumper Settings
Jumper
J11
J12
Position
1 – 2
2 – 3
1 – 2
2 – 3
Purpose
1-30 HP, 240VDC
2-60 HP, 500VDC
Jumper
J11
J12
Position
1 – 2
2 – 3
1 – 2
2 – 3
Purpose
40-100 HP, 240VDC
75-200 HP, 500VDC
Series A Series B
115VAC Motor Thermal Input
24VDC Motor Thermal Input
115VAC Reset Input
24VDC Reset Input
24VDC Motor Thermal Input
115VAC Motor Thermal Input
24VDC Reset Input
115VAC Reset Input
Jumper
J11
J12
Position
1 – 2
2 – 3
1 – 2
2 – 3
Purpose
125-300 HP, 240VDC
250-600 HP, 500VDC
Series B
MKVA
115VAC Motor Thermal Input
24VDC Motor Thermal Input
115VAC Reset Input
24VDC Reset Input
3. Verify Encoder supply voltage and output voltage return to the drive. If
an encoder is used, the drive can provide +12VDC (500 mA) to power
the encoder. If a 5VDC supply is required it must be externally
sourced. Jumpers J8 through J10 on the Main Control Board must be
set for the appropriate output voltage of the encoder which is fed back
to the drive. Check the encoder documentation to determine which
voltage is to be used. See Table 6.J for jumper settings.
Table 6.J
Main Control Board Jumper Settings (connected jumpers)
Jumper
J8
J9
J10
+5VDC Position
1 – 2
1 – 2
1 – 2
Purpose
Encoder Voltage Selection
Encoder Voltage Selection
Encoder Voltage Selection
+12VDC Position
2 – 3
2 – 3
2 – 3
NOTE: The encoder jumpers J8 – J10 are set for the voltage output of the encoder.
Jumper
J14
Position
1 – 2
2 – 3
Purpose
EE Write Enabled
EE Write Disabled
